Om3 12 Fibers MPO-LC Fiber Optic Patch Cord

Brand Name : XDK

Model Number : G652D/G657A1/G657A2

Certification : ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS

Place of Origin : China/Vietnam

MOQ : negotiable

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30KM/day

Delivery Time : 5-8 work days

Packaging Details : regular packaging

Fiber Count : 12-144core

Sheath Color : According to the standard, can be required

Length : 2KM (can be required)

Feature : Hydrolysis resistant

Contact Now

Om3 12 Fibers MPO-LC Fiber Optic Patch Cord

Features
1) Good mechanical and temperature performance.
2) High strength loose tube that is hydrolysis retardant.

3) Special tube filling compound ensure a critical protection of fiber.

4) Special desighed compact structure is good at preventing loose tubes from shrinking.
5) Crush resistance and flexibility.

Technical Information

Fiber Count Struture Fibers Per Tube Loose Tube Diameter(mm) Cable Weight(Kg/km) Tensile Strength Long/Short Term(N) Crush Resistance Long/Short Term(N/100mm) Bending Radius Static/Dynamic
12 1＋5 6 1.7±0.1 84 600/1500 300/1000 10D/20D
24 1＋5 6 1.7±0.1 85 600/1500 300/1000 10D/20D
48 1＋5 12 2.0±0.1 99 600/1500 300/1000 10D/20D
72 1＋6 12 2.0±0.1 122 600/1500 300/1000 10D/20D
96 1＋8 12 2.0±0.1 149 600/1500 300/1000 10D/20D
144 1＋12 12 2.0±0.1 212 600/1500 300/1000 10D/20D

Om3 12 Fibers MPO-LC Fiber Optic Patch Cord


The color code of the tubes and the idividual fibers, shall be in accordance with the table as below.

Standard Color Identification
NO. 1 2 3 4 5 6
Color Blue Orange Green Brown Slate White
NO. 7 8 9 10 11 12
Color Red Black Yellow Violet Pink Aqua

Color 13~24 will be marked with a black tracer
For black color no need marked black tracer, will use nature color instead


Packing Informations
1) Packing material: Wooden drum
2) Packing length: standard length of cable shall be 2 km. Other cable length is also available if required by customer

Our certificates
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH

Fiber Optic Cable Mechanical Performance Testing Laboratory
1) Main Testing Type: Precision Test and Mechanical Test.
2) Precision Testing Machine: EXFO OTDR, EG&G PMD-440,CD-400.
3) Mechanical Performance Testing : Temperature, Impact, Tensile, Bending, Torsion, Flexing, Winding, Vibration, Water Penetration, Fusion Splicer, Water Penetration.

Our advantages
1) Professional cable manufacturer
2) About 20 years experiences in cable industry
3) MOQ just 1Km
4) ISO, UL , ROSH,REACH...certifications
5) Can be customized production of fiber optic cable


Product Tags:

RoHS Outdoor Fiber Optic Cable



GYTS Indoor Fiber Optic Cable



2KM indoor optical fiber cable


Quality Om3 12 Fibers MPO-LC Fiber Optic Patch Cord wholesale

Om3 12 Fibers MPO-LC Fiber Optic Patch Cord Images
