Sc-Sc Multimode Om1 62.5/125um Duplex Fiber Optic Patch Cord

Brand Name : XDK

Model Number : G652D/G657A1/G657A2

Certification : ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS

Place of Origin : China/Vietnam

MOQ : negotiable

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30KM/day

Delivery Time : 5-8 work days

Packaging Details : regular packaging

Fiber Sort : Single mode: G652, G657, Multi mode: OM1, OsM2,OM3,OM4.

Fiber Count : Simplex

Tight Buffer Material : PVC (LSZH,Hytrel,PA or Customer required)

Jacket Material : PVC, LSZH (can be required)

Jacket Color : Blue, Yellow or White

Length : 2KM (can be required)

Contact Now

Product Description

XDK Group has a strict quality control system ISO9001, and the fiber patch cord meets the CE and RoHS

certifications which are required by European markets. There are 1.6mm 3.0mm 2.0mm diameter cables for choice,

the cable color can be customized to white, aqua and so on.

Specification

Parametor	Unit	Value
Connector Type		FC/UPC,FC/APC,SC/UPC,LC/UPC,LC/APC,ST/PC,MPO
Fiber Type		Multi-Mode	Single Mode
Insertion Loss	dB	Max.≤0.2	Max.≤0.3
Return Loss(Typ.)	dB	≥36(no APC connector)	/PC	/UPC	/APC
Return Loss(Typ.)	dB	≥36(no APC connector)	≥45	≥50	≥60
Repeatability	dB	≤0.1
Interchangeability	dB	≤0.2
Connection Durability	times	≥1000
Operating/Storage Temperature	℃	-40~+80

Sc-Sc Multimode Om1 62.5/125um Duplex Fiber Optic Patch Cord

Requirement for Order
1) Fiber sort: Single mode:G652,G657, Multi mode:OM1,OM2,OM3,OM4.
2) Fiber brand: YOFC, Corning, Fiberhome,Fujikura,OFS etc.
3) Jacket material: PVC,LSZH ( can be required).
4) The fiber and tube color: according to stranded color, can be required.
5) Length of cable: generally is 2KM, can be required.
6) Other requirement: can be negotiated.

Packing Informations
1) Packing material: Wooden drum
2) Packing length: standard length of cable shall be 2 km. Other cable length is also available if required by customer

Our certificates
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH

Testing Lab

No	Device name	No	Device name
1	Optical time domain reflectometer (OTDR)	8	GNZV Cable Torsion Testing Machine
2	Fiber Polarization Mode Dispersion	9	GQNV Cable Flexing Testing Machine
3	Fiber Dispersion ,Strain Tester	10	GJRV Cable Winding Testing Machine
4	High Low Temperature Test Chamber	11	GZDV Cable Vibration Testing Machine
5	Cable Impact Testing Machine	12	Cable Water Penetration Test
6	Cable Squash Tensile Testing Machine	13	Fusion Splicer
7	GWQV Cable Bending Tester	14	Cable Water Penetration Test Rig

Our advantages
1) Professional cable manufacturer
2) About 20 years experiences in cable industry
3) MOQ just 1Km
4) ISO, UL , ROSH,REACH...certifications
5) Can be customized production of fiber optic cable

Sc-Sc Multimode Om1 62.5/125um Duplex Fiber Optic Patch Cord Images
