fiber optic patch cord lc sc apc upc ftth fiber optic pigtails jumper

Brand Name : XDK

Model Number : G652D/G657A1/G657A2

Certification : ISO, OHSAS18001,RoHS,CRP,UL

Place of Origin : China/Vietenam

MOQ : 1

Payment Terms : L/C, D/A, D/P, Western Union, T/T

Supply Ability : 5000000m/month

Delivery Time : around 5 working days

Packaging Details : customizable

Application : Indoor any purpose cable distribution

Model number : GJDFJV

Lead time : within one week

Packing : Negotiable

Strength member : Aramid yarn

Fiber type : Single mode or Multi mode

Fiber number : 4-12 cores

Contact Now

fiber optic patch cord lc sc apc upc ftth fiber optic pigtails jumper

Product profile

The Pre-terminated bow type drop optical cable is our company's optical fiber movable connection device

specially designed for fiber to the home (FTTH). It adopts the form of factory pre- terminated and provides an

excellent alternative solution for the connection of the drop cable.

Product feature
•Low insertion loss, high return loss.
•Good versatility and interchangeability stable and reliable connection, high repeatability.
•Outstanding tensile performance and convenient construction.
•Fully compatible with ordinary optical fiber connectors.


Application
•Use of optical fiber communication in harsh outdoor environment.
•Optical fiber to the home (FTTH) ODN system.
•Introduce connection from outdoor to indoor equipment.

No. 1 2 3 4 5 6
Color Blue Orange Green Brown Gray White
No. 7 8 9 10 11 12
Color Red Black Yellow Violet Pink Aqua

fiber optic patch cord lc sc apc upc ftth fiber optic pigtails jumper

6,Cable marking and cable reel marking

6.1 Cable marking

The cable sheath shall be marked with white characters at intervals of one meter with following information:

(1) Purchaser’s name

(2) Cable type

(3) Fiber type and counts

(4) Year of manufacture

(5) Length marking

Notice: cable mark is available if requested by customer.

6.2 Cable reel

Details given below shall be marked with a weather materials on both outer sides of the reel flange :

(1) Cable type and fiber counts

(2) Length of cable in meters

(3) Year of manufacture

Notice: shipping mark is available if requested by customer.

7. Packing Informations

(1) Packing material: Wooden drum

(2) Packing length: standard length of cable shall be 2 km. Other cable length is also available if required by customer
